Oxygen Acetylene Hose

PARAMETERS：



I.D.		O.D.	W.P.		B.P.		WEIGHT	LENGTH MAX.
MM	INCH	MM	MPA	PSI	MPA	PSI	KG/M	M/ROLL
5	3/16"	12	0.63~2.0	92~300	2.0~6.0	280~900	0.13	100±1%
6	1/4"	13	0.63~2.0	92~300	2.0~6.0	280~900	0.17	100±1%
8	5/16"	15	0.63~2.0	92~300	2.0~6.0	280~900	0.23	100±1%
10	3/8"	17	0.63~2.0	92~300	2.0~6.0	280~900	0.25	100±1%
13	1/2"	22	0.63~2.0	92~300	2.0~6.0	280~900	0.36	100±1%
16	5/8"	25	0.63~2.0	92~300	2.0~6.0	280~900	0.53	100±1%





An oxygen acetylene hose, also known as a welding hose, is a type of hose that is used to convey oxygen and acetylene gas to welding, cutting, and brazing equipment. These hoses are essential for oxy-fuel welding and cutting processes, which involve the use of oxygen and acetylene to create a high-temperature flame for melting and cutting metal. Here are some key features and applications of oxygen acetylene hoses:



Material:Oxygen acetylene hoses are typically made from a blend of synthetic rubbers that can withstand the chemical properties of oxygen and acetylene. The internal tube is designed to be resistant to the specific type of gas being transported.



Reinforcement: Many oxygen acetylene hoses have a reinforcement layer, such as textile or steel braiding, to enhance their strength and pressure resistance.



Safety:Hoses for oxygen and acetylene are often color-coded for easy identification. Oxygen hoses are typically green, while acetylene hoses are red. This color-coding helps prevent dangerous mix-ups and ensures safety during use.

Temperature Range:Oxygen acetylene hoses are built to handle the high temperatures associated with welding and cutting processes.



Chemical Resistance:These hoses are resistant to the chemicals found in oxygen and acetylene, which helps prevent degradation of the hose material over time.





Welding: Oxygen acetylene hoses are used in welding applications to create an oxy-fuel flame for melting and joining metal.

Cutting: They are used in cutting processes where a high-temperature flame is used to heat metal to its melting point, allowing for precise cutting.

Brazing:Brazing processes also use oxygen acetylene hoses to create a controlled flame for joining metals with a filler material.

Always inspect the hose regularly for signs of wear, damage, or leaks, and replace it when necessary to ensure safety. It's also important to follow the manufacturer's recommendations for installation and maintenance to ensure the hose operates effectively and safely. Additionally, it's crucial to store and handle oxygen and acetylene cylinders and hoses according to safety guidelines to prevent accidents and ensure the integrity of the equipment.
