Suction and Discharge Oil Hose
SUCTION AND DISCHARGE OIL HOSE
Tube: black, smooth, NBR rubber.
Reinforcement: high strength synthetic cord, anti-static copper wire available, and steel helix wire.
Cover: black, wrapped finish, synthetic rubber, weathering and oil resistant.
Temperature: -20℃ to 80℃
Application: Mandrel hard wall hose used for the suction and delivery of petroleum products with aromatic content up to 30%.
Description
Oil suction and delivery rubber hose can be applicable to suction and discharge gasoline, kerosene, diesel, engine oil, heavy oil and other mineral oils at normal temperature.
Characteristics: Suction and discharge oil hose is good in flexibility. The body is solid. The hose has the double properties of bearing both the positive and negative pressure. The performance of the hose remains good even under the pressure of -80KPa(600mm mercury) at the vacuum. The burst pressure of the hose is four times or higher than the working pressure. Outer layer's ozone-resistance property conform to the standard of ISO 7326:2006, IDT.
PARAMETERS：
|
I.D |
O.D |
W.P. |
B.P. |
WEIGHT |
LENGTH MAX. |
|
|
MM |
INCHI |
MM |
MPA |
MPA |
KG/M |
M/ROLL |
|
25 |
1" |
36 |
0.3~1.0 |
0.9~3.0 |
0.9 |
60 |
|
32 |
1.1/4" |
45 |
0.3~1.0 |
0.9~3.0 |
1.1 |
60 |
|
38 |
1.1/2" |
52 |
0.3~1.0 |
0.9~3.0 |
1.3 |
60 |
|
51 |
2" |
65 |
0.3~1.0 |
0.9~3.0 |
1.4 |
60 |
|
64 |
2.1/2" |
80 |
0.3~1.0 |
0.9~3.0 |
1.8 |
60 |
|
76 |
3" |
94 |
0.3~1.0 |
0.9~3.0 |
2.1 |
60 |
|
90 |
3.1/2" |
108 |
0.3~1.0 |
0.9~3.0 |
3 |
60 |
|
102 |
4" |
122 |
0.3~1.0 |
0.9~3.0 |
3.7 |
60 |
|
127 |
5" |
172 |
0.3~1.0 |
0.9~3.0 |
4.8 |
40 |
|
152 |
6" |
182 |
0.3~1.0 |
0.9~3.0 |
7 |
40 |
|
203 |
8" |
240 |
0.3~1.0 |
0.9~3.0 |
10 |
20 |
Suction & Discharge Oil Hose are available in 10bar/20bar.
