Description
Part No.: 22641/22641-W/ 22641-T
Features:
45° BSPP Female 60° Cone
* Material: Carbon Steel
* Surface Treatment: Zinc, Trivalent Chromate Plating
* Salt Spray Test: 96h Corrosion Resistent
Description: 22641 45° BSP FEMALE 60° CONE SEAT HYDRAULIC HOSE FITTING
| PART NO. | THREAD E | HOSE BORE | DIMENSIONS | ||||
| DN | DASH | A | C | H | S2 | ||
| 22641-04-04 | G1/4"X19 | 6 | 4 | 42.3 | 5.5 | 20.2 | 19 |
| 22641-06-04 | G3/8"X19 | 6 | 4 | 43.2 | 6.3 | 21 | 22 |
| 22641-06-05 | G3/8"X19 | 8 | 5 | 45.3 | 6.3 | 22 | 22 |
| 22641-06-06 | G3/8"X19 | 10 | 6 | 46.9 | 6.3 | 22.6 | 22 |
| 22641-08-08 | G1/2"X14 | 12 | 8 | 61.1 | 7.5 | 26.1 | 27 |
| 22641-10-08 | G5/8"X14 | 12 | 8 | 61.4 | 9.5 | 26.5 | 30 |
| 22641-10-10 | G5/8"X14 | 16 | 10 | 72.6 | 9.5 | 27.8 | 30 |
| 22641-12-10 | G3/4"X14 | 16 | 10 | 73 | 10.9 | 28.2 | 32 |
| 22641-12-12 | G3/4"X14 | 20 | 12 | 79.2 | 10.9 | 31.8 | 32 |
| 22641-16-16 | G1"X11 | 25 | 16 | 88.4 | 11.7 | 34.2 | 41 |
| 22641-08-06T | G1/2"X14 | 10 | 6 | 48.1 | 7.5 | 23.9 | 27 |
| 22641-12-08T | G3/4"X14 | 12 | 8 | 61.8 | 10.9 | 26.9 | 32 |
| 22641-16-12T | G1"X11 | 20 | 12 | 80.8 | 11.7 | 33.4 | 41 |
| 22641-20-16T | G1.1/4"X11 | 25 | 16 | 85.3 | 11 | 31.1 | 50 |
| 22641-20-20W | G1.1/4"X11 | 32 | 20 | 98.8 | 11 | 38 | 50 |
| 22641-24-24W | G1.1/2"X11 | 40 | 24 | 116.8 | 13 | 45.5 | 55 |
| 22641-32-32W | G2"X11 | 50 | 32 | 135.7 | 16 | 52.7 | 70 |
| Note: 1.For use with braided hoses. 2. If use with spiral hoses, hose fitting series number is 22642-xx-xx | |||||||
We, LOMOFLEX CO.,LTD are a pressional factory to produce international standard hydraulic components. We have been engaged in hydraulic components, hydraulic hose, industrial hose, various customized hydraulic parts' design and production for thirteen years. We integrates R&D, manfacturing and sales into one, with the right of import and exprot business.
